HOBBES NETmapper Pro & SmartProbe Kit

HOBBES NETmapper Pro & SmartProbe Kit

Please log in to be able to use the shopping cart and then complete orders.

Log in
Ordered until 3 pm - usually dispatched on the same day
Item no. 13.01.3274-1
Brand / Manufacturer HOBBES
Manuf. no. 256850PK
EAN 7630049698062
Package weight 0.673 kg


  • Displays the Ethernet port status: Identifies Speed up to Giga (10/100/1000)
  • Ping default router, DNS Server and user defined device
  • Scans and lists all the PC Host with IP address and computer host name or MAC address
  • PC Host service detects: HTTP/Telnet/DHCP/FTP and SNMP services
  • Incorporates port-finder function: locate corresponding socket on 10/100M or giga hub/switch
  • Wire map results are displayed in a pin–to–pin format
  • Remote ID number indication for recognition on workstations
  • RJ-45 ports on main unit for either On–line or Off–line Test
  • Measures cable length without remote of Cat5, Cat5e, Cat6 and Cat7 cables
  • Self–calibrating ability for non–standard cable tester (length test) and/or to increase measuring accuracy
  • User define unit of measurement in meter or feet for cable length tests
  • The Tone Generator function sends 1kHz tone on all pins with 4 special tonalities (The Digital generator function sends single tone and dual tone)
  • Automatically detects PoE devices and voltage

Display: LCD
Connector type: RJ-45
Accuracy: ±2m less than 10m, ±5% over 10m (32.81ft.)
Test range for cable length: 1 to 300m
Split pairs detection: Minimum 1.5m
Tone generator: Single/dual digital tone
Operating temp. : 0ºC to 50ºC
Storage temp. : -30℃ to 50℃
Humidity: 10% to 90%
Master Dimensions: 110 x 78 x 31mm
Remote Dimensions: 44 x 32 x 28.5mm
Weight: 145g
Battery: AAA Alkaline battery x 4


Manufacturer HOBBES
Product group Tester
Product type Cable tester
Accessories: Rechargeable battery/battery required Micro battery (AAA), 04x
Weight 318.2 g
Height of packaging (single piece) 80 mm
Width of packaging (single piece) 160 mm
Depth of packaging (single piece) 280 mm
Package weight (single piece) 0.673 kg


Manufacturer data sheet - English (353.5 KB)


User manual - English (2.1 MB)
