ROLINE 19" Automatic Transfer Switch, 2x C20 to 6x C13/2x C19, 16A

ROLINE 19" Automatic Transfer Switch, 2x C20 to 6x C13/2x C19, 16A

Please log in to be able to use the shopping cart and then complete orders.

Log in
Available
Ordered until 3 pm - usually dispatched on the same day
Item no. 19.07.3415-1
Brand / Manufacturer ROLINE
Manuf. no. 19.07.3415
EAN 7630049629134
Package weight 5.4 kg

Description

The Automatic Transfer Switch (ATS) is a high availability device designed for providing redundant power for sensitive electronic equipment. Powered by two independent power sources, it makes a rapid switch from one source to the other automatically, when the power supply used to power its connected load fails.

  • The ATS - Automatic Transfer Switch - has two main supplies that provide redundant power to connected IT equipment
  • Designed to supply power from the primary source "A". If this source is unavailable for any reason, the device will automatically switch to the secondary source "B", with no interruption to the connected equipment
  • Once the primary source "A" is available again, it will automatically switch back, again without interruption to the equipment
  • Robust steel construction
  • 2x C20 16A inlets
  • 2x C19 16A outlets
  • 6x C13 10A unswitched sockets
  • 19" horizontal rack mounting 1U (44.4mm) high
  • 16A max. rated. 220 - 240VAC 50Hz

Specifications

Manufacturer ROLINE
Product group UPS Accessories
Product type Automatic Transfer Switch (ATS)
Colour black
Scope of delivery User manual, 2x Input cables: C19-C20, 2x Input cable lockers, SNMP card, accessories for rack installation
Dimensions (HxWxD) 44 x 482.6 x 220 mm
Mounting form 19" Rackmount
Technical particularity Supports SNMP Version3
Operating temperature min. 0 °C
Operating temperature max. 45 °C
Height 44 mm
Width 482.6 mm
Depth 220 mm
Weight 3079.7 g
Height of packaging (single piece) 140 mm
Width of packaging (single piece) 440 mm
Depth of packaging (single piece) 550 mm
Package weight (single piece) 5.4 kg
