Description

• ROLINE Fibre Optic Jumper Cables with OM3 quality for high performance wiring
• The quality of the connectors and fibres and an optimal assembly procedure lead to extremely good characteristics in respect of insertion loss and reflection
• Compact conductor (fibre movable in secondary coating)
• Duplex Cable with fibre type Muliti-mode 50/125µm, OM3
• Cable construction: Aramid yarn strain relief, PVC outer coating, Ø 2.8 x 6 mm
• Color: turquoise

Specifications

Manufacturer	ROLINE
Product group	Fibre optic cable
Product type	Fibre Optic Jumper Cables OM3
Colour	turquoise
Length	0.5 m
Quantity of fibre	2
Conductor composition	Compact conductor
Cable type	Duplex Cable
External cable	no
Fibre section	Multi mode 50/125µm OM3
Connection ports	LC / ST
Side 1 Connector Type	LC
Side 2 Connector Type	ST
Colour (Cable)	turquoise
Aramid strain relief	yes
External cable diameter	2,8x6 mm
Mantle of external cable	PVC
Cable LSOH	no
Max. insertion loss	0.3 dB
Operating temperature min.	-20 °C
Operating temperature max.	70 °C
Storage temperature min.	-40 °C
Storage temperature max.	80 °C
Weight	16 g
Height of packaging (single piece)	10 mm
Width of packaging (single piece)	200 mm
Depth of packaging (single piece)	180 mm
Package weight (single piece)	0.04 kg

Downloads

Product data sheet - English (37.4 KB)

Download

Manufacturer data sheet - English (118.5 KB)

Download
