Description

5-Port Gigabit network switch for use in a industrial environment - including an additional SFP-Port!

• Provides 5x 10/100/1000Mbps copper ports + 1x dual SFP slot
• Auto-negotiation
• Auto MDI/MDI-X crossover function
• Provides in-band web-based management interface
• Supports IEEE 802.3x flow control for full duplex
• Supports back pressure flow control for half duplex
• Supports port-based and 802.1Q Tag-based VLAN
• Provides QoS function
• Provides 802.1x authentication
• Supports configuration backup and upload

• Provides port mirroring function
• Supports 802.1w RSTP
• Provides IGMP snooping
• MAC Address Table 8K entries
• Buffer Memory 136K bytes
• Operating Power: +7VDC to +57VDC
• DC Power Input Screwed Terminal Block: +7VDC - +57VDC
• DC IN Jack: -D 6.3mm/+D 2.0mm

Specifications

Manufacturer	ROLINE
Product group	Network Switches
Product type	Gigabit Ethernet Switch
Colour	black
Network standard	Gigabit Ethernet
LAN (Mbps)	10/100/1000
Quantity of ports	6
Gigabit Ethernet Ports RJ-45	5
Free slots for SFPs	1
Mounting form	DIN Rail
Stackable	no
Dimensions (HxWxD)	26 x 104.5 x 144 mm
Power supply	External power supply unit
Mains connection	Loose cable / screw terminals
Height	26 mm
Width	104.5 mm
Depth	144 mm
Weight	443.2 g
Height of packaging (single piece)	70 mm
Width of packaging (single piece)	150 mm
Depth of packaging (single piece)	200 mm
Package weight (single piece)	0.8 kg

Downloads

Product data sheet - English (45.8 KB)

Download

Manufacturer data sheet - English (162.1 KB)

Download
