Description

The ROLINE Gigabit PoE Injector is a so-called PSE, a unit to supply power for e.g. surveillance cameras, and LAN devices such as access points, bridges and routers over Ethernet cable.

A PSE supplies the power together with the data in the network cable.There is no longer need for an additional own power supply of the device.

• Supply of data and power into the network cables
• Connectors: 1x RJ-45 port (Data In, Data input), 1x RJ-45 port (Data & Power Out, output data and power)
• Compatible with 802.3af and 802.3at
• Power via PoE++: up to 90W
• LED indicators for Power status, PD mode detection
• Output voltage: 56V DC
• Contents: Injector, manual

Specifications

Manufacturer	ROLINE
Product group	PoE adapter
Product type	Gigabit PoE-Injector
Colour	black
Power over Ethernet (PoE)	PoE++
Quantity of PoE ports	1
Max. PoE output power per port	90 W
Max. PoE output power (total)	90 W
Dimensions (HxWxD)	76.5 x 159 x 39 mm
Mains connection	Cold appliance connection
Height	76.5 mm
Width	159 mm
Depth	39 mm
Weight	593.4 g
Height of packaging (single piece)	50 mm
Width of packaging (single piece)	140 mm
Depth of packaging (single piece)	230 mm
Package weight (single piece)	0.9 kg
