ROLINE LineSecure III 2000 - Line Interactive UPS

ROLINE LineSecure III 2000 - Line Interactive UPS

Please log in to be able to use the shopping cart and then complete orders.

Log in
Available
Ordered until 3 pm - usually dispatched on the same day
Item no. 19.40.1124
Brand / Manufacturer ROLINE
Manuf. no. 19.40.1124
EAN 7630049627987
Package weight 18.28 kg
Output (VA/W)
Interface
ROLINE

Description

The ROLINE LineSecure UPS series uses line-interactive technology and is used wherever reliable protection is required.

The LineSecure III UPS series, with its intelligent design and pure sine wave output for connected applications, is the best choice for office, SOHO, and home applications. It provides high-quality pure sine wave output for connected critical devices. Additionally equipped with an AVR (Automatic Voltage Regulator), it stabilizes fluctuating voltages such as overvoltages and undervoltages as well as other voltage problems and provides a stable output voltage for the most important devices. The LS III series is equipped with a color LCD display that shows the UPS status and increases user-friendliness. The LS III series offers power protection, including overload, surge, and short-circuit protection. The USB port allows you to monitor UPS status, schedule UPS events, and receive instant notifications via a computer system or portable device. It also has a slot for an SNMP/web card.

In areas with significant voltage fluctuations, the UPS uses buck and boost regulation to compensate for differences between the input and target voltage. The battery management system monitors the UPS batteries and only charges them when necessary, extending battery life by up to 50%.

  • RS232 interface
  • USB interface
  • Operating display via LCD panel
  • Battery management
  • Automatic voltage regulation
  • Tel/modem protection
  • SNMP/WEB via optional LAN adapter
  • Sine wave output

Specifications

Manufacturer ROLINE
Product group UPS
Product type UPS Line Interactive
Colour black
Scope of delivery UPS, Software, Cable Set
Classification (IEC 62040-3) VI-SS-333
UPS technology Line Interactive
Power class 2000 ... 3000 VA
Output (VA/W) 2000 / 1600
Efficiency 95 %
Backup time 3 min
Backup time full/half-load 3 / 6 min
Dimensions (HxWxD) 140 x 380 x 210 mm
Mounting form Tower
Voltage (input) 230 V +- 10%
Voltage (output) 230 V
Frequency 50 Hz
Connector type (input) Cold Connector IEC320 C14
Outputs 8
Connector type (output) 8x Cold Connector IEC320 C13
Phase in/output 230V/230V / 50Hz
Over current protection EMI,- RFI-Filter
Max. quantity of delay expansion units 0
Delay expansion unit --
Slots for adapter card 0
Slot for adapter card 1
Acoustic level < 40 dB
Interface USB, RS232
RS-232 Interface yes
USB 2.0 Interface yes
Hot swap batteries no
Bypass no
Additional over current protector Telephone/Fax
Activity Display
Activity LED ---
Activity Display LCD
incl.Management Software Windows
Internal cooling Active, fan
Ambient temperature 0-40°C
Operating temperature min. 0 °C
Operating temperature max. 40 °C
Height 210 mm
Width 140 mm
Depth 380 mm
Weight 17.5 kg
Height of packaging (single piece) 320 mm
Width of packaging (single piece) 270 mm
Depth of packaging (single piece) 490 mm
Package weight (single piece) 18.28 kg
