ROLINE ProSecure II 1000 RM1U - Online UPS, 19" Rack Version
Please log in to be able to use the shopping cart and then complete orders.
Log inDescription
The ROLINE ProSecure Series - for optimum power protection is a truly state of the art online double conversion UPS, ideal for all essential computer systems and servers. Protects against: power failure, power sag, power surge, under voltage, over voltage, switch transient, line noise, frequency variation, harmonic distortion.Product features:
- Cold start function (DC power on)
- Lightning and surge protection
- Battery replacement warning
- Emergency Power Off function
- Battery remain time display
- LCD display front panel
- Power factor correction
- Support USB communication
- Multiple language LCD display
- On line output voltage selected
- Hot swappable battery by user
- True on-line technology provides all power protection
- Pure sine-wave output with less than 3% THD
- Fully digitized microprocessor controlled
- Short Circuit and overload protection
- Advanced
- Automatic battery charge in UPS off mode
- Automatic diagnostics & battery check
- RS-232 communication port with monitoring software
- Network/fax/modem surge protection
- Extended back up time with battery pack
- Load segmentation receptacles controllable
- High efficiency mode selectable
- Fan speed auto control when loads varies
- UPS Management Software : Windows NT/ 2k / XP / 7 / 8 /Server 2003 / 2008 / 2012 x86/x64,
- Contents: UPS, cable set, UPS management software
Specifications
Manufacturer | ROLINE |
---|---|
Product group | UPS |
Product type | UPS Online, Rackmount |
Colour | grey |
Scope of delivery | UPS, Software, Cable Set |
Classification (IEC 62040-3) | VFI-SS-111 |
UPS technology | Online |
Power class | 1000 ... 1900 VA |
Output (VA/W) | 1000 / 700 |
Efficiency | 95 % |
Backup time | 2 min |
Backup time full/half-load | 2,5 / 9 min |
Dimensions (HxWxD) | 44 x 428 x 610 mm; 1 HE |
Mounting form | Rackmount |
Voltage (input) | 160-230V |
Voltage (output) | 230V |
Output voltage regulation | ± 2% |
Frequency | 50Hz ± 3% |
Connector type (input) | cold connector IEC 320 C14 |
Outputs | 4 |
Connector type (output) | 4x cold connector IEC 320 C13 |
Phase in/output | 230V/230V / 50Hz |
Over current protection | EMI,- RFI-Filter |
Max. quantity of delay expansion units | 2 |
Delay expansion unit | 2 |
Slots for adapter card | 1 |
Slot for adapter card | 1 |
Interface | RS232, USB |
RS-232 Interface | yes |
USB 2.0 Interface | yes |
Hot swap batteries | Yes, front side |
Bypass | Automatic + manual |
Additional over current protector | no |
Activity | Display |
Activity LED | 5 |
Activity Display | LCD |
incl.Management Software | Windows |
Internal cooling | Active, fan |
Ambient temperature | 0-40C |
Operating temperature min. | 0 °C |
Operating temperature max. | 40 °C |
Height | 44 mm |
Width | 428 mm |
Depth | 610 mm |
Weight | 16 kg |
Height of packaging (single piece) | 170 mm |
Width of packaging (single piece) | 540 mm |
Depth of packaging (single piece) | 640 mm |
Package weight (single piece) | 18.074 kg |
Back up time
Power rating (VA / W) | with 0 / 1 / 2 Battery pack (minutes), according to manufacturer |
---|---|
1000/700 | 2,4 |
900/630 | 3,5 |
800/560 | 4,3 |
700/490 | 5,1 |
600/420 | 6,7 |
500/350 | 9,3 |
400/280 | 12,1 |
300/210 | 19,7 |
200/140 | 35,2 |
100/70 | 80 |
