ROLINE ProSecure II 1000 RM2U - Online UPS, 19" Rack Version

Please log in to be able to use the shopping cart and then complete orders.

Available

Ordered until 3 pm - usually dispatched on the same day

Item no.	19.40.1089
Brand / Manufacturer	ROLINE
Manuf. no.	19.40.1089
EAN	7611990154890
Package weight	25 kg
Output (VA/W)
Interface

Description

The ROLINE ProSecure Series - for optimum power protection is a truly state of the art online double conversion UPS, ideal for all essential computer systems and servers. Protects against: power failure, power sag, power surge, under voltage, over voltage, switch transient, line noise, frequency variation, harmonic distortion.

Product features:

Cold start function (DC power on)
Lightning and surge protection
Battery replacement warning
Emergency Power Off function
Battery remain time display
LCD display front panel
Power factor correction
Support USB communication
Multiple language LCD display
On line output voltage selected
Hot swappable battery by user
True on-line technology provides all power protection
Pure sine-wave output with less than 3% THD
Fully digitized microprocessor controlled
Short Circuit and overload protection
Advanced

management (ABM)

Automatic battery charge in UPS off mode
Automatic diagnostics & battery check
RS-232 communication port with monitoring software
Network/fax/modem surge protection
Extended back up time with battery pack
Load segmentation receptacles controllable
High efficiency mode selectable
Fan speed auto control when loads varies
UPS Management Software : Windows NT/ 2k / XP / 7 / 8 /Server 2003 / 2008 / 2012 x86/x64,

MAC OS X (Intel) 10.6.x, 10.7.x, 10.8.x Mountain Lion, 10.9.x MavericksMAC OS, LINUX

Contents: UPS, cable set, UPS management software

Specifications

Manufacturer	ROLINE
Product group	UPS
Product type	UPS Online, Rackmount
Colour	grey
Scope of delivery	UPS, Software, Cable Set
Classification (IEC 62040-3)	VFI-SS-111
UPS technology	Online
Power class	1000 ... 1900 VA
Output (VA/W)	1000 / 700
Efficiency	95 %
Backup time	5 min
Backup time full/half-load	5 / 9 min
Dimensions (HxWxD)	88 x 428 x 425 mm; 2 HE
Mounting form	Rackmount
Voltage (input)	160-230V
Voltage (output)	230V
Output voltage regulation	± 2%
Frequency	50Hz ± 3%
Connector type (input)	cold connector IEC 320 C14
Outputs	4
Connector type (output)	4x cold connector IEC 320 C13
Phase in/output	230V/230V / 50Hz
Over current protection	EMI,- RFI-Filter
Max. quantity of delay expansion units	2
Delay expansion unit	2
Slots for adapter card	1
Slot for adapter card	1
Interface	RS232, USB
RS-232 Interface	yes
USB 2.0 Interface	yes
Hot swap batteries	Yes, front side
Bypass	Automatic + manual
Additional over current protector	no
Activity	Display
Activity LED	5
Activity Display	LCD
incl.Management Software	Windows
Internal cooling	Active, fan
Ambient temperature	0-40°C
Operating temperature min.	0 °C
Operating temperature max.	40 °C
Height	88 mm
Width	428 mm
Depth	425 mm
Weight	17 kg
Height of packaging (single piece)	200 mm
Width of packaging (single piece)	550 mm
Depth of packaging (single piece)	740 mm
Package weight (single piece)	25 kg

Back up time

Power rating (VA / W)	with 0 / 1 / 2 Battery pack (min)
1000/700	6 / 33 / 67
900/630	7 / 39 / 77
800/560	8 / 45 / 87
700/490	10 / 55 / 102
600/420	13 / 67 / 125
500/350	18 / 80 / 150
400/280	24 / 105 / 200
300/210	38 / 150 / 280
200/140	60 / 240 / 450
100/70	95 / 500 / 900

Downloads

Product data sheet - English (42.2 KB)

Download

User manual - Deutsch (9.8 MB)

Download

User manual - English (9.8 MB)

Download
