Log inManufacturer | ROLINE |
---|---|
Product group | UPS |
Product type | UPS Online, Rackmount |
Colour | grey |
Scope of delivery | UPS, Software, Cable Set |
Classification (IEC 62040-3) | VFI-SS-111 |
UPS technology | Online |
Power class | 2000 ... 3000 VA |
Output (VA/W) | 2000 / 1400 |
Efficiency | 95 % |
Backup time | 6 min |
Backup time full/half-load | 6 / 10 min |
Dimensions (HxWxD) | 88 x 428 x 610 mm; 2 HE |
Mounting form | Rackmount |
Voltage (input) | 160-230V |
Voltage (output) | 230V |
Output voltage regulation | ± 2% |
Frequency | 50Hz ± 3% |
Connector type (input) | IEC 320 C20 |
Outputs | 5 |
Connector type (output) | 4 x IEC 320 C13; 1 x IEC 320 C19 |
Phase in/output | 230V/230V / 50Hz |
Over current protection | EMI,- RFI-Filter |
Max. quantity of delay expansion units | 2 |
Delay expansion unit | 2 |
Slots for adapter card | 1 |
Slot for adapter card | 1 |
Interface | RS232, USB |
RS-232 Interface | yes |
USB 2.0 Interface | yes |
Hot swap batteries | Yes, front side |
Bypass | Automatic + manual |
Additional over current protector | no |
Activity | Display |
Activity LED | 5 |
Activity Display | LCD |
incl.Management Software | Windows |
Internal cooling | Active, fan |
Ambient temperature | 0-40°C |
Operating temperature min. | 0 °C |
Operating temperature max. | 40 °C |
Height | 88 mm |
Width | 428 mm |
Depth | 610 mm |
Weight | 32 kg |
Height of packaging (single piece) | 220 mm |
Width of packaging (single piece) | 550 mm |
Depth of packaging (single piece) | 740 mm |
Package weight (single piece) | 34.5 kg |
Power rating (VA / W) | with 0 / 1 / 2 Battery pack (min) |
---|---|
2000/1400 | 6 / 33 / 67 |
1800/1260 | 7 / 39 / 77 |
1600/1120 | 8 / 45 / 87 |
1400/980 | 10 / 55 / 102 |
1200/840 | 13 / 67 / 125 |
1000/700 | 18 / 80 / 150 |
800/560 | 24 / 105 / 200 |
600/420 | 38 / 150 / 280 |
400/280 | 60 / 240 / 450 |
200/140 | 95 / 500 / 900 |
