Description

For charging or as a PSU over the USB port of your device. Fast charging through Quick Charge 3.0!

• For charging of mobile devices (tablets / smartphones)
• Multi-Protection: Over Current / Short Circuit / Over Voltage Protection
• Compact Design
• Identifies what kind of device is plugged into and delivers the proper voltage/amperage
• Input: 100 - 240 V AC, 50 - 60 Hz
• Output: 5V/2.4A - 3A, 9V-3A, 12V/3A, 15V/3A, 20V/3A, 20.3V/3A (max. 61 W)

Specifications

Manufacturer	ROLINE
Product group	Voltage converter
Product type	USB charger
Colour	white
Input	100-240 VAC
Output	5V/2,4A - 3A, 9V-3A, 12V/3A, 15V/3A, 20V/3A, 20,3V/3A (max. 61 W)
Output	61W
Dimensions (HxWxD)	55 x 29 x 88 mm
Output connector	1x USB Type C F PD (PowerDelivery)
Regional use	Europe except Ireland, Malta, Cyprus, United Kingdom
Mains connection	Euro plug, Type-C
Height	55 mm
Width	29 mm
Depth	88 mm
Weight	117.6 g
Height of packaging (single piece)	30 mm
Width of packaging (single piece)	170 mm
Depth of packaging (single piece)	180 mm
Package weight (single piece)	0.165 kg
