VALUE Cableadapter, v1.2, DP M - HDMI F

VALUE Cableadapter, v1.2, DP M - HDMI F

Please log in to be able to use the shopping cart and then complete orders.

Log in
Available
Ordered until 3 pm - usually dispatched on the same day
Item no. 12.99.3144-10
Brand / Manufacturer VALUE
Manuf. no. 12.99.3144
EAN 7611990935819
Package weight 0.04 kg

Description

DisplayPort to HDMI cable adapter for connecting a graphics card with DP to a monitor with HDMI connection - with a resolution of up to 3840x2160 @30Hz!

  • If you want to connect a graphic card with DisplayPort Female to a monitor by using a HDMI cable, you need this DisplayPort to HDMI adapter
  • Connectors: DisplayPort Male, HDMI Female
  • DisplayPort Version 1.2 allows increased resolutions, higher refresh rates, and greater color depth
  • Remark: The DisplayPort-HDMI adapter is only working in one direction: the DisplayPort plug has to be connected to the source device (e.g. graphic card)

Specifications

Manufacturer VALUE
Product group Adapters, Terminators, Converters
Product type DisplayPort-HDMI Adapter
Colour black
Length 0.15 m
Max. resolution 3840 x 2160 @30Hz (4K, Full HD)
Side 1 connection (PC) DisplayPort Male
Side 2 connection (Peripherals) HDMI Female
Side 1 Connector Type DisplayPort
Side 1 Connector Gender Male
Side 2 Connector Type HDMI Type A
Side 2 Connector Gender Female
Active / Passive Passive
Area of application External
Dimensions (HxWxD) 14 x 44 x 44 mm
Technical particularity DisplayPort Version 1.2
Height 14 mm
Width 44 mm
Depth 44 mm
Weight 26.1 g
Height of packaging (single piece) 15 mm
Width of packaging (single piece) 190 mm
Depth of packaging (single piece) 190 mm
Package weight (single piece) 0.04 kg

Downloads

Product data sheet - English (52.8 KB)

Download

Manufacturer data sheet - English (1.2 MB)

Download
